Stainless Steel Power Roller Conveyor China Supplier
Features of Stainless Steel Power Roller Conveyor: Stainless steel material is corrosion-resistant and has good corrosion resistance, heat resistance, low temperature strength and mechanical properties.
The stainless steel power roller conveyor is suitable for conveying all kinds of boxes, bags, pallets, etc. Bulk materials, small items or irregular items need to be transported on pallets or in turnover boxes. It can transport a single piece of heavy material, or bear a large impact load. It is easy to connect and filter between roller lines. Multiple roller lines and other conveyors or special machines can be used to form a complex logistics conveying system to complete various process needs. . The accumulation and release roller can be used to realize the accumulation and transportation of materials.
The stainless steel power roller conveyor line is simple in structure, high in reliability and easy to use and maintain. The roller conveyor is suitable for conveying items with a flat bottom, and is mainly composed of a driving roller, a frame, a bracket, and a driving part. It has the characteristics of large conveying capacity, fast speed, light operation, and can realize multi-variety collinear and diverted conveying.
Structural form of stainless steel roller conveyor: According to the driving mode, it can be divided into power roller line and non-power roller line, and according to the layout form, it can be divided into horizontal conveying roller line, inclined conveying roller line and turning roller line. It can also be specially designed according to customer requirements to meet the requirements of various customers. It is a commonly used conveying equipment in the logistics conveying system.
Stainless steel roller conveyor standard gauge roller line width is 200, 300, 400, 500, 1200mm, etc. Stainless steel roller conveyors can also adopt other special specifications according to customer requirements. The standard turning inner radius of the turning roller line is 600, 900, 1200mm, etc., and other special specifications can also be adopted according to customer needs. The diameters of the rollers used for the straight rollers are 38, 50, 60, 76, 89mm, etc.
Selection parameters of roller conveyor
1. Length selection of drum:
Goods with different widths should choose rollers suitable for the width, and generally use "transportation +50mm".
2. Selection of wall thickness and shaft diameter of the drum:
According to the weight of the conveyed material, it is evenly distributed to the contacting rollers, and the required load-bearing capacity of each roller is calculated to determine the wall thickness and shaft diameter of the roller.
3. Roller material and surface treatment:
According to the different conveying environment, determine the material and surface treatment (carbon steel galvanized, stainless steel, blackening or rubber coating) of the roller.
4. Select the installation method of the roller:
According to the specific requirements of the overall conveyor, choose the installation method of the roller: spring press-in type, internal tooth shaft type, full flat tenon type, through shaft pin hole type, etc.
For the tapered drum of the bending machine, the width and taper of the rolling surface depend on the size of the goods and the turning radius.
Stainless Steel Power Roller Conveyor China Supplier
Features of Stainless Steel Power Roller Conveyor: Stainless steel material is corrosion-resistant and has good corrosion resistance, heat resistance, low temperature strength and mechanical properties.
The stainless steel power roller conveyor is suitable for conveying all kinds of boxes, bags, pallets, etc. Bulk materials, small items or irregular items need to be transported on pallets or in turnover boxes. It can transport a single piece of heavy material, or bear a large impact load. It is easy to connect and filter between roller lines. Multiple roller lines and other conveyors or special machines can be used to form a complex logistics conveying system to complete various process needs. . The accumulation and release roller can be used to realize the accumulation and transportation of materials.
The stainless steel power roller conveyor line is simple in structure, high in reliability and easy to use and maintain. The roller conveyor is suitable for conveying items with a flat bottom, and is mainly composed of a driving roller, a frame, a bracket, and a driving part. It has the characteristics of large conveying capacity, fast speed, light operation, and can realize multi-variety collinear and diverted conveying.
Structural form of stainless steel roller conveyor: According to the driving mode, it can be divided into power roller line and non-power roller line, and according to the layout form, it can be divided into horizontal conveying roller line, inclined conveying roller line and turning roller line. It can also be specially designed according to customer requirements to meet the requirements of various customers. It is a commonly used conveying equipment in the logistics conveying system.
Stainless steel roller conveyor standard gauge roller line width is 200, 300, 400, 500, 1200mm, etc. Stainless steel roller conveyors can also adopt other special specifications according to customer requirements. The standard turning inner radius of the turning roller line is 600, 900, 1200mm, etc., and other special specifications can also be adopted according to customer needs. The diameters of the rollers used for the straight rollers are 38, 50, 60, 76, 89mm, etc.
Selection parameters of roller conveyor
1. Length selection of drum:
Goods with different widths should choose rollers suitable for the width, and generally use "transportation +50mm".
2. Selection of wall thickness and shaft diameter of the drum:
According to the weight of the conveyed material, it is evenly distributed to the contacting rollers, and the required load-bearing capacity of each roller is calculated to determine the wall thickness and shaft diameter of the roller.
3. Roller material and surface treatment:
According to the different conveying environment, determine the material and surface treatment (carbon steel galvanized, stainless steel, blackening or rubber coating) of the roller.
4. Select the installation method of the roller:
According to the specific requirements of the overall conveyor, choose the installation method of the roller: spring press-in type, internal tooth shaft type, full flat tenon type, through shaft pin hole type, etc.
For the tapered drum of the bending machine, the width and taper of the rolling surface depend on the size of the goods and the turning radius.
